Waterproof Directional MIMO Panel Antenna，5.8GHz Outdoor Directional Panel Antenna

Specification

700-3800 14dBi Outdoor 5G Antenna Waterproof Directional MIMO Panel Antenna

5.8GHz Outdoor Directional Panel Antenna

Frequency Range ： 700-3800MHz

Gain ： 14dBi

Half power lobe width ： Horizontal:90°

： Vertical:15°

Than before and after ： ≥23dB

Isolation ： ≥30dB

The input impedance ： 50Ω

VSWR ： ≤1.5

Maximum input po ： 100W

Lightning protection ： The dc grounding

Mechanical and environmental indicators ：

Connector ： 2×N Female

The antenna size ： 500×128×56mm

Antenna weight ： 1.5kg

Antenna Package size ： 600×230×160mm

Antenna cover material ： UPVC

Reflector color ： gray

Mechanically adjustable dip Angle ： 0～15°

Working temperature ： -40～60℃

Extreme wind speed ： 60 m/s

Derrick diameter ： 35～75mm
