| Electrical | ||
| Characteristic Impedance | 50ohm | |
| Frequency Range | DC-3GHz | |
| VSWR | ≤1.20@DC3GHz | |
| Insertion Loss | ≤0.05dB√f(GHz)dB | |
| Dielectric Withstanding Voltage | ≥2500V RMS,50Hz,at sea level | |
| Working Vlotage | 500 W @2GHz/90℃ | |
| RF Power | 3KW(max.) | |
| Dielectric Resistance | ≥5000MΩ | |
| Contact Resistance | Center Contact ≤1.0mΩ | |
| Outer Contact ≤1.0mΩ | ||
Specification
Application scenario
| Mechanical | ||
| Durability | Mating cycles ≥500 | |
| Material and Plating | ||
| Parts Name | Material | Plating |
| Body | Brass | Tri-alloy |
| Insulator | PTFE | — |
| Center conductor | Phosphor Bronze | Ag |
| Coupling nut | Brass | Tri-alloy |
| Ferrule | Brass | Ni |
| Gasket | Silicone rubber | — |
| Environmental | ||
| Temperature Range | -85℃~+320℃ | |
| Weatherproof Rate | IP67 | |
| RoHS | Compliant | |
